Posts https://filograsso.it/en/posts Tue, 01 Oct 2024 17:45:32 +0000 en-US <![CDATA[Do you have an old lock with double bit technology? Protect it now!!!]]> Tue, 01 Oct 2024 17:45:32 +0000 How do I know what kind of lock my door has? Together today we will understand how to intercept the type of lock that is on your security door, of technologies on the Italian and European market on armored/armored doors for the majority there are two main ones: Double map European profile wrench Let’s start with the Double Map Double bit locks were the first locks to be installed on security doors, so much so that they are still installed on 70 percent of the security doors in Italy today. Although this technology was the best in the 1970s-80s, today it has become obsolete and easily manipulated. The internal mechanics of a double bit lock are made of mechanisms, springs and plates, the latter made with various sizes and tolerances create different combinations of each other, which only by creating keys with correct heights and positions can the lock work. Over the years and with the advent of decoders created specifically for this type of technology, opening such a lock has really become child’s play. This type of device is self-coding facilitated by the fact that this type of lock has a low number of plates and above all heights. What things can I do to protect my door if it has this type of lock? To secure a door equipped with a double bit lock there are only and exclusively two solutions. The first is to install a magnetic shutter defender specifically for double-bitted technologies, and the second is to upgrade the door by installing a new lock with a punched key (called a European Key by everyone). Installing a magnetic double map defender is the least invasive solution, but nevertheless the most vulnerable, in fact sometimes this defender is fixed on the panel so it is easily detached from the door, however if it is installed properly it can be an almost complete solution to keep the old lock. The best solution, however, is still to upgrade the door with a new European cylinder technology, clearly one that is of excellent quality and has extremely high security parameters, Obviously this solution is the most invasive because installing a European cylinder lock will mean making changes. To sum up, the double-bit lock has accompanied us for several decades protecting us from theft and violations of our homes. Today, however, it is time to continue to protect ourselves by not neglecting our doors that help us preserve our privacy and security every day.

How do I know what kind of lock my door has?

Together today we will understand how to intercept the type of lock that is on your security door, of technologies on the Italian and European market on armored/armored doors for the majority there are two main ones:

Double map

European profile wrench

Let’s start with the Double Map

Double bit locks were the first locks to be installed on security doors, so much so that they are still installed on 70 percent of the security doors in Italy today. Although this technology was the best in the 1970s-80s, today it has become obsolete and easily manipulated.

The internal mechanics of a double bit lock are made of mechanisms, springs and plates, the latter made with various sizes and tolerances create different combinations of each other, which only by creating keys with correct heights and positions can the lock work.

Over the years and with the advent of decoders created specifically for this type of technology, opening such a lock has really become child’s play. This type of device is self-coding facilitated by the fact that this type of lock has a low number of plates and above all heights.

What things can I do to protect my door if it has this type of lock?

To secure a door equipped with a double bit lock there are only and exclusively two solutions. The first is to install a magnetic shutter defender specifically for double-bitted technologies, and the second is to upgrade the door by installing a new lock with a punched key (called a European Key by everyone).

Installing a magnetic double map defender is the least invasive solution, but nevertheless the most vulnerable, in fact sometimes this defender is fixed on the panel so it is easily detached from the door, however if it is installed properly it can be an almost complete solution to keep the old lock.

The best solution, however, is still to upgrade the door with a new European cylinder technology, clearly one that is of excellent quality and has extremely high security parameters, Obviously this solution is the most invasive because installing a European cylinder lock will mean making changes.

To sum up, the double-bit lock has accompanied us for several decades protecting us from theft and violations of our homes. Today, however, it is time to continue to protect ourselves by not neglecting our doors that help us preserve our privacy and security every day.

]]> <![CDATA[Counterdefender: a little-known but very effective device]]> Sun, 18 Aug 2024 18:12:35 +0000 What is counterdefender? Today we are talking about a little-known device in the security industry, the COUNTERDEFENDER. Let’s start with the fact that the counter-defender is a device that protects the European cylinder from being pushed inward, but in addition to this function it plays another very important role, not to be underestimated when you have a door with a European cylinder lock, in fact thanks to its compliance it protects the defender from being torn and pulled out. And yes because as we all know the pins of the defender pass through metal sleeves that sometimes when pulling the defender they pull out together with the pins. And because of its plate base this makes the fastening compartment a single, very strong block. There are three versions of the counterdefender, recessed, for exposed tang and adjustable to thread. Flush and exposed counterdefender for cylinder with knob or tang As we said before there are three versions, now let’s talk about the recessed one and the visible one for cylinders with knob or tang. Let’s start with the recessed one, the recessed counterdefender comes from an idea of ours, which is to lower the traditional counterdefender so that it is recessed inside the door so that if you have a cylinder with a tang or knob this you can recess it into the panel making the cylinder and defender compartment more stable, leaving a flawless exterior finish. The same function does the fixed exposed counterdefender for cylinders with a knob or tang, with the difference that to bring it into view then to the same panel for a good finish it must perforce be shimmed, this factor although it might seem a small detail in reality would involve the use of longer pins, which in pulling might allow bending and twisting that do not do well you have pins in forcing. This version is also sometimes used for cylinders that have a key inside, although not recommended. And yes because an adjustable, threaded product is born for cylinders with an internal key. Adjustable counterdefender for cylinders with key also inside. This visible adjustable version was born with a very specific purpose, that of being able to hold the counterdefender firmly to the lock, therefore hardly shimming, using shorter fixing pins so as not to allow bending of the whole protection compartment. The function of this product is really simple, in fact it will be enough to fix its base directly by leaning it against the lock, once everything is fixed it will be enough to screw on the steel anti-thrust cover and adjust it with its thread to the exact size of the cylinder. After adjusting everything with the two supplied pins you have to lock the ferrule so as not to allow rotational movements, after all these arrangements you will just have to fit the cover in the color chosen and suitable for your door so as to ensure a flawless aesthetic. This product can be paired with multiple models of plates so that no old marks are left on your door. Factors to consider: Although perfectly designed, this product has some details to consider: It should always be combined with defender with anti-tear technology. The hole on the door must be at least 52 mm, since it has a diameter of 50 mm. Verify that you are purchasing the counterdefender with the appropriate escutcheon with depth suitable for your door. What is counterdefender?

Today we are talking about a little-known device in the security industry, the COUNTERDEFENDER. Let’s start with the fact that the counter-defender is a device that protects the European cylinder from being pushed inward, but in addition to this function it plays another very important role, not to be underestimated when you have a door with a European cylinder lock, in fact thanks to its compliance it protects the defender from being torn and pulled out. And yes because as we all know the pins of the defender pass through metal sleeves that sometimes when pulling the defender they pull out together with the pins. And because of its plate base this makes the fastening compartment a single, very strong block. There are three versions of the counterdefender, recessed, for exposed tang and adjustable to thread.

Flush and exposed counterdefender for cylinder with knob or tang

As we said before there are three versions, now let’s talk about the recessed one and the visible one for cylinders with knob or tang. Let’s start with the recessed one, the recessed counterdefender comes from an idea of ours, which is to lower the traditional counterdefender so that it is recessed inside the door so that if you have a cylinder with a tang or knob this you can recess it into the panel making the cylinder and defender compartment more stable, leaving a flawless exterior finish.

The same function does the fixed exposed counterdefender for cylinders with a knob or tang, with the difference that to bring it into view then to the same panel for a good finish it must perforce be shimmed, this factor although it might seem a small detail in reality would involve the use of longer pins, which in pulling might allow bending and twisting that do not do well you have pins in forcing. This version is also sometimes used for cylinders that have a key inside, although not recommended. And yes because an adjustable, threaded product is born for cylinders with an internal key.

Adjustable counterdefender for cylinders with key also inside.

This visible adjustable version was born with a very specific purpose, that of being able to hold the counterdefender firmly to the lock, therefore hardly shimming, using shorter fixing pins so as not to allow bending of the whole protection compartment. The function of this product is really simple, in fact it will be enough to fix its base directly by leaning it against the lock, once everything is fixed it will be enough to screw on the steel anti-thrust cover and adjust it with its thread to the exact size of the cylinder. After adjusting everything with the two supplied pins you have to lock the ferrule so as not to allow rotational movements, after all these arrangements you will just have to fit the cover in the color chosen and suitable for your door so as to ensure a flawless aesthetic. This product can be paired with multiple models of plates so that no old marks are left on your door.

Factors to consider:

Although perfectly designed, this product has some details to consider:

It should always be combined with defender with anti-tear technology.

The hole on the door must be at least 52 mm, since it has a diameter of 50 mm.

Verify that you are purchasing the counterdefender with the appropriate escutcheon with depth suitable for your door.

]]> <![CDATA[Impression technique: is it really dangerous for all cylinders?]]> Tue, 16 Jul 2024 18:19:25 +0000 The Lock Picking Technique of Impression on European Cylinder: Complete Guide Lock picking is a skill that never ceases to amaze in its complexity and precision. Among the various lock picking techniques, impression picking stands out for its ability to create a duplicate key without having the original available. This technique becomes even more fascinating when applied to European cylinders, known for their security and widespread use. In this article, we will explore the impressioning technique applied to European cylinders in detail, analyzing the process, the tools needed, and ethical considerations. What is the Impression Technique? The impressioning technique involves creating a working key for a lock from a lowered key blank covered with adhesive aluminum. This technique takes advantage of the softness of aluminum to self-impress the encryption on the key. The European cylinder, known for its strength and security, presents an interesting challenge for lock pickers. Tools Needed To apply the impression technique on a European cylinder, you will need: Lowered Rough Key: Specifically for the European cylinder. Pliers: For manipulating the key blank. Soft adhesive aluminum: To imprint the encryption on the key. Specific Challenges of European Cylinders European cylinders are designed to provide a high level of security, and they have certain features that make the impression technique particularly challenging: Anti-Drill Pins: These pins are designed to make it more difficult to manipulate the lock. High Quality Springs: Stronger springs can make it more difficult to leave clear marks on the rough a key’aluminum. Customized profiles: Cylinders with milled and particular key profiles or very small holes make it impossible to make an impression. Reduced Tolerances: The accuracy required to duplicate a key for a European cylinder is extremely high, making any error potentially critical. Ethical and Legal Considerations As with all lock picking techniques, it is critical to practice impressioning in a legal and ethical manner. Unauthorized duplication of keys can have serious legal consequences. This technique should be used only with the lock owner’s permission and in legal contexts, such as for creating legitimate duplicates or for educational purposes. Conclusion The impressioning technique applied to European cylinders presents a fascinating challenge for anyone interested in lock picking. It requires precision, patience, and a high level of manual skill. While it is an advanced technique, the satisfaction of creating a working key without having the original is priceless. Always remember to practice lock picking responsibly, respecting the laws and rights of others. If you are passionate about lock picking and want to deepen your knowledge, keep following our blog for more guides, techniques, and insights! The Lock Picking Technique of Impression on European Cylinder: Complete Guide

Lock picking is a skill that never ceases to amaze in its complexity and precision. Among the various lock picking techniques, impression picking stands out for its ability to create a duplicate key without having the original available. This technique becomes even more fascinating when applied to European cylinders, known for their security and widespread use. In this article, we will explore the impressioning technique applied to European cylinders in detail, analyzing the process, the tools needed, and ethical considerations.

What is the Impression Technique?

The impressioning technique involves creating a working key for a lock from a lowered key blank covered with adhesive aluminum. This technique takes advantage of the softness of aluminum to self-impress the encryption on the key. The European cylinder, known for its strength and security, presents an interesting challenge for lock pickers.

Tools Needed

To apply the impression technique on a European cylinder, you will need:

  • Lowered Rough Key: Specifically for the European cylinder.
  • Pliers: For manipulating the key blank.
  • Soft adhesive aluminum: To imprint the encryption on the key.

Specific Challenges of European Cylinders

European cylinders are designed to provide a high level of security, and they have certain features that make the impression technique particularly challenging:

  • Anti-Drill Pins: These pins are designed to make it more difficult to manipulate the lock.
  • High Quality Springs: Stronger springs can make it more difficult to leave clear marks on the rough a key’aluminum.
  • Customized profiles: Cylinders with milled and particular key profiles or very small holes make it impossible to make an impression.
  • Reduced Tolerances: The accuracy required to duplicate a key for a European cylinder is extremely high, making any error potentially critical.

Ethical and Legal Considerations

As with all lock picking techniques, it is critical to practice impressioning in a legal and ethical manner. Unauthorized duplication of keys can have serious legal consequences. This technique should be used only with the lock owner’s permission and in legal contexts, such as for creating legitimate duplicates or for educational purposes.

Conclusion

The impressioning technique applied to European cylinders presents a fascinating challenge for anyone interested in lock picking. It requires precision, patience, and a high level of manual skill. While it is an advanced technique, the satisfaction of creating a working key without having the original is priceless. Always remember to practice lock picking responsibly, respecting the laws and rights of others.

If you are passionate about lock picking and want to deepen your knowledge, keep following our blog for more guides, techniques, and insights!

]]> <![CDATA[Disec MR423: A defender designed well but sold poorly.]]> Mon, 15 Jul 2024 17:57:05 +0000 How is the Disec MR423 composed? Today we are talking about the magnetic protector for Dierre European cylinder locks with a security grade 4. This defender replaces the traditional 42 mm defender fitted as standard on Dierre brand armored doors. Its body is made entirely of steel, but the central part is made of stainless steel. This version produced by Disec is a really effective product but only if it is sold with the right criteria. The Body The Disec MR423 is similar to the MR500 version, with a smaller size of 42 mm and not 50 and is sold without any strain relief device, the front rotating part is made of stainless steel. Inside it is a combination of magnets and positions. These combinations create really special and complex cipher systems. Thanks to its stepping technology, the key is interrogated several times during rotation, ensuring extreme protection against manipulation. The filling function Key plugging is done by a rotation of the plate made of stainless steel operated by its key made with a combination of vectors and positions. These details give the defender a high degree of security with an unparalleled system of operation. And thanks to the protections and details with which it is made, drilling is a distant memory. Its details and materials make this accessory an excellent deterrent against acid. The reason why he was born Disec MR423 was created with a very specific purpose, namely to facilitate the securing of a Dierre lock security door as long as it has the anti-intrusion system, this is for the simple fact that it does not have any anti-intrusion badge but is to be sold bare and then to be combined with the traditional Dierre badges with plastic underplate. Factors to consider: Although perfectly designed, this product has some details to consider: It should always be combined with cylinders that have key necks at least 15 mm long. ALWAYS make sure that the lock on which it is installed has the locking device that is activated when the defender and cylinder are broken, otherwise you will incur changes and expenses made unnecessarily. Even if you choose gold and bronze finish the defender will always have the central part made of hardened stainless steel in steel color. For added security remember to always close the defender, because if we leave the defender open we make this shutter keyed. This defender was created as a key shutter and not as an anti-knockout protection so evaluate well the degree of security you want to achieve. Verify that you purchase the defender with the appropriate escutcheon with depth suitable for your door. How is the Disec MR423 composed?

Today we are talking about the magnetic protector for Dierre European cylinder locks with a security grade 4. This defender replaces the traditional 42 mm defender fitted as standard on Dierre brand armored doors. Its body is made entirely of steel, but the central part is made of stainless steel. This version produced by Disec is a really effective product but only if it is sold with the right criteria.

The Body

The Disec MR423 is similar to the MR500 version, with a smaller size of 42 mm and not 50 and is sold without any strain relief device, the front rotating part is made of stainless steel. Inside it is a combination of magnets and positions. These combinations create really special and complex cipher systems. Thanks to its stepping technology, the key is interrogated several times during rotation, ensuring extreme protection against manipulation.

The filling function

Key plugging is done by a rotation of the plate made of stainless steel operated by its key made with a combination of vectors and positions. These details give the defender a high degree of security with an unparalleled system of operation. And thanks to the protections and details with which it is made, drilling is a distant memory. Its details and materials make this accessory an excellent deterrent against acid.

The reason why he was born

Disec MR423 was created with a very specific purpose, namely to facilitate the securing of a Dierre lock security door as long as it has the anti-intrusion system, this is for the simple fact that it does not have any anti-intrusion badge but is to be sold bare and then to be combined with the traditional Dierre badges with plastic underplate.

Factors to consider:

Although perfectly designed, this product has some details to consider:

It should always be combined with cylinders that have key necks at least 15 mm long.

ALWAYS make sure that the lock on which it is installed has the locking device that is activated when the defender and cylinder are broken, otherwise you will incur changes and expenses made unnecessarily.

Even if you choose gold and bronze finish the defender will always have the central part made of hardened stainless steel in steel color.

For added security remember to always close the defender, because if we leave the defender open we make this shutter keyed.

This defender was created as a key shutter and not as an anti-knockout protection so evaluate well the degree of security you want to achieve.

Verify that you purchase the defender with the appropriate escutcheon with depth suitable for your door.

]]> <![CDATA[Disec MR500Y: an underrated defender]]> Wed, 10 Jul 2024 22:13:09 +0000 How is the Disec MR500Y composed? Today we discuss the magnetic protector for European cylinder locks with a security grade 4. This defender is really simple and effective. Its body is made entirely of steel, but the central part is made of stainless steel. This chosen version has a really special detail and by reading this article you will be captivated. The Body The Disec MR500Y is similar to the MAG3G version, however, the thing that differentiates it is its showcase, the front rotating part is made of stainless steel. Inside it is a combination of magnets and positions. These combinations create really special and complex cipher systems. Thanks to its stepping technology, the key is interrogated several times as it rotates, ensuring extreme protection against manipulation. The filling function Key plugging is done by a rotation of the plate made of stainless steel operated by its key also made with a combination of vectors and positions. These details give the defender a high degree of security with an unparalleled system of operation. And thanks to the protections and details with which it is made, puncture is a distant memory. thanks to its details and materials MR500 is an excellent deterrent against acid. His insignia The insignia of the Disec MR500Y is a really technical insignia, because it is made in an oval shape and even if gripped with force, it spins free on the defender making gripping the defender impossible. In addition to this peculiarity Disec has well decided to make the badge have meticulous adjustment, thanks to its free bushing adjustment system with screw-on panel fixing. A system that will make perfect installation on your door so that there will be no annoying play as there is on traditional spring defenders. Obviously, the 500Y badge is a really effective prototype because one even if attached remains free but not removable. Special and protective feature. Factors to consider: Although perfectly designed, this product has some details to consider: It should always be combined with cylinders that have key necks at least 15 mm long. The hole on the door needs to be at least 56/57 mm, since it has an inner reveal of 54 mm. Even if you choose gold and bronze finish the defender will always have the central part made of hardened stainless steel in steel color. For added security remember to always close the defender, because if we leave the defender open we make this shutter keyed. Verify that you purchase the defender with the appropriate escutcheon with depth suitable for your door. More product photos: How is the Disec MR500Y composed?

Today we discuss the magnetic protector for European cylinder locks with a security grade 4. This defender is really simple and effective. Its body is made entirely of steel, but the central part is made of stainless steel. This chosen version has a really special detail and by reading this article you will be captivated.

The Body

The Disec MR500Y is similar to the MAG3G version, however, the thing that differentiates it is its showcase, the front rotating part is made of stainless steel. Inside it is a combination of magnets and positions. These combinations create really special and complex cipher systems. Thanks to its stepping technology, the key is interrogated several times as it rotates, ensuring extreme protection against manipulation.

The filling function

Key plugging is done by a rotation of the plate made of stainless steel operated by its key also made with a combination of vectors and positions. These details give the defender a high degree of security with an unparalleled system of operation. And thanks to the protections and details with which it is made, puncture is a distant memory. thanks to its details and materials MR500 is an excellent deterrent against acid.

His insignia

The insignia of the Disec MR500Y is a really technical insignia, because it is made in an oval shape and even if gripped with force, it spins free on the defender making gripping the defender impossible. In addition to this peculiarity Disec has well decided to make the badge have meticulous adjustment, thanks to its free bushing adjustment system with screw-on panel fixing. A system that will make perfect installation on your door so that there will be no annoying play as there is on traditional spring defenders. Obviously, the 500Y badge is a really effective prototype because one even if attached remains free but not removable. Special and protective feature.

Factors to consider:

Although perfectly designed, this product has some details to consider:

It should always be combined with cylinders that have key necks at least 15 mm long.

The hole on the door needs to be at least 56/57 mm, since it has an inner reveal of 54 mm.

Even if you choose gold and bronze finish the defender will always have the central part made of hardened stainless steel in steel color.

For added security remember to always close the defender, because if we leave the defender open we make this shutter keyed.

Verify that you purchase the defender with the appropriate escutcheon with depth suitable for your door.

More product photos:

]]> <![CDATA[Tokoz PRO400 Version 2024: The stainless steel disc cylinder.]]> Sun, 07 Jul 2024 11:50:51 +0000 What is the Tokoz PRO 400? Today we’re talking about the Tokoz PRO400, the top-of-the-range cylinder produced by the Czech manufacturer. This type of product is gaining in popularity on the European and Italian markets. The body The Tokoz PRO 400 has a modular body, created with inserts that stack on top of each other, to protect against breakage there’s a steel bar that’s riveted to the cylinder body, this technology allows really long cylinder dimensions. Its internal mechanism is made entirely of STAINLESS STEEL, with discs that create a unique combination. Inside is a single active pin that acts as a step counter and prevents key extraction during rotation. The encryption compartment is inserted into the key insert from the rear, giving the cylinder excellent protection against extraction. To protect the bore, there’s a hardened steel washer that acts as a defender for the internal cipher. The front of the body is also in hardened steel, with a thickness of almost 5 mm. When you insert the wrench, a quarter-turn is made to align the discs, and only if the wrench is the right one will it engage the bar that allows the cam to turn. Another feature of this product is that the discs, combined with their thickness, make the keyway a single body. The key The PRO 300 key is made of ALPACCA, a light, resistant material. This new key has replaced the old brass one, which was too flexible and caused breakage. The key is flat and SIMMETRIC. This feature makes the key reversible; its shape is reminiscent of the old double-bitted key technology. Of course, its disk system is much more secure, because at the end of the rotation, the cylinder only allows the key to be removed after resetting the encryption by forcing a quarter-turn before extracting the key. Its ASYMMETRIC head provides an excellent grip when turning, and thanks to the small number of pins and springs inside the cylinder, key insertion is very easy. The length of the key neck is approximately 16 mm, making the cylinder compatible with 90% of magnetic or mechanical protectors. The most important factors : Even if made of hard metal and equipped with an anti-puncture and anti-shattering system, this product should always be combined with a magnetic or mechanical protector. Equipped with a stainless steel disc mechanism, a slight friction will be felt during rotation due to the friction of the various discs. If, prior to this product, you had a cylinder with spring-and-pin technology, you may find the problem of resetting the encryption annoying, as once the process of opening/closing the lock is complete, you are obliged to reset the key. More product photos : What is the Tokoz PRO 400?

Today we’re talking about the Tokoz PRO400, the top-of-the-range cylinder produced by the Czech manufacturer. This type of product is gaining in popularity on the European and Italian markets.

The body

The Tokoz PRO 400 has a modular body, created with inserts that stack on top of each other, to protect against breakage there’s a steel bar that’s riveted to the cylinder body, this technology allows really long cylinder dimensions.

Its internal mechanism is made entirely of STAINLESS STEEL, with discs that create a unique combination. Inside is a single active pin that acts as a step counter and prevents key extraction during rotation. The encryption compartment is inserted into the key insert from the rear, giving the cylinder excellent protection against extraction. To protect the bore, there’s a hardened steel washer that acts as a defender for the internal cipher. The front of the body is also in hardened steel, with a thickness of almost 5 mm. When you insert the wrench, a quarter-turn is made to align the discs, and only if the wrench is the right one will it engage the bar that allows the cam to turn. Another feature of this product is that the discs, combined with their thickness, make the keyway a single body.

The key

The PRO 300 key is made of ALPACCA, a light, resistant material. This new key has replaced the old brass one, which was too flexible and caused breakage.

The key is flat and SIMMETRIC. This feature makes the key reversible; its shape is reminiscent of the old double-bitted key technology. Of course, its disk system is much more secure, because at the end of the rotation, the cylinder only allows the key to be removed after resetting the encryption by forcing a quarter-turn before extracting the key.

This image has a smaller alt attribute; the date name is image-8.png

Its ASYMMETRIC head provides an excellent grip when turning, and thanks to the small number of pins and springs inside the cylinder, key insertion is very easy. The length of the key neck is approximately 16 mm, making the cylinder compatible with 90% of magnetic or mechanical protectors.

The most important factors :

Even if made of hard metal and equipped with an anti-puncture and anti-shattering system, this product should always be combined with a magnetic or mechanical protector.

Equipped with a stainless steel disc mechanism, a slight friction will be felt during rotation due to the friction of the various discs.

If, prior to this product, you had a cylinder with spring-and-pin technology, you may find the problem of resetting the encryption annoying, as once the process of opening/closing the lock is complete, you are obliged to reset the key.

More product photos :

This image has a smaller alt attribute; the date name is image-4-1.png
]]> <![CDATA[Kaba Expert Cross Lam: the cylinder with extreme security !!!!]]> Sun, 07 Jul 2024 10:13:01 +0000 Do you know Kaba Expert Cross Lam? Today we’re talking about a high-security cylinder with a very special technology. It comes from Austrian company DORMA-KABA, one of the leaders in access control and security. Expert Cross is the flagship of the Austrico brand, and offers a very high level of security. The body The Kaba Expert Cross has a unique, non-modular body, which makes it more secure, but it also relies on a special unbreakable technology called LAM. This system consists of 3 hardened steel plates embedded in the single body, making it a truly robust cylinder. The internal mechanism is pin-based, with a mixture of conventional and pointed pins. There are no less than four radial rows of 25 pins, arranged in different increments to strike the key at different points and angles. Inside are two active pins that align a moving ball in the key. The springs and pins are located only in the round part of the cylinder (the head). Therefore, even if the lower part of the cylinder is pierced, it is impossible to access the spring compartment. The housing also contains a hardened steel anti-pin. Despite the 25 pins inside, key insertion is very specific and smooth, as is rotation, which is frictionless during movement. The key The Kaba Expert Cross Lam key is made from ALPACCA, a lightweight, durable material. Its rounded shape prevents damage even in the event of an accidental drop. The key is flat and symmetrical. This feature makes the key reversible, with a very small, unobtrusive shape. The key features an active pin that can move freely and is not limited by springs. This detail is important for two reasons: firstly, it protects against illegal copying of the key by 3D or 4D printing, and secondly, the two active pins in the cylinder that align the ball are very difficult to manipulate. The length of the key neck is approximately 17 mm, making the cylinder 100% compatible with magnetic or mechanical protection devices. With this product, Kaba offers end-users optimum convenience with maximum security. My comments: Although composed of feathers and tips, this product is not handled. The 25 work spindles are very special and precise, guaranteeing extreme safety. The small key takes up very little space and, thanks to its scratch-proof design, will not damage pockets, trouser pockets, etc.

Do you know Kaba Expert Cross Lam?

Today we’re talking about a high-security cylinder with a very special technology. It comes from Austrian company DORMA-KABA, one of the leaders in access control and security. Expert Cross is the flagship of the Austrico brand, and offers a very high level of security.

The body

The Kaba Expert Cross has a unique, non-modular body, which makes it more secure, but it also relies on a special unbreakable technology called LAM. This system consists of 3 hardened steel plates embedded in the single body, making it a truly robust cylinder.

The internal mechanism is pin-based, with a mixture of conventional and pointed pins. There are no less than four radial rows of 25 pins, arranged in different increments to strike the key at different points and angles. Inside are two active pins that align a moving ball in the key. The springs and pins are located only in the round part of the cylinder (the head). Therefore, even if the lower part of the cylinder is pierced, it is impossible to access the spring compartment. The housing also contains a hardened steel anti-pin. Despite the 25 pins inside, key insertion is very specific and smooth, as is rotation, which is frictionless during movement.

The key

The Kaba Expert Cross Lam key is made from ALPACCA, a lightweight, durable material. Its rounded shape prevents damage even in the event of an accidental drop.

The key is flat and symmetrical. This feature makes the key reversible, with a very small, unobtrusive shape. The key features an active pin that can move freely and is not limited by springs. This detail is important for two reasons: firstly, it protects against illegal copying of the key by 3D or 4D printing, and secondly, the two active pins in the cylinder that align the ball are very difficult to manipulate. The length of the key neck is approximately 17 mm, making the cylinder 100% compatible with magnetic or mechanical protection devices. With this product, Kaba offers end-users optimum convenience with maximum security.

My comments:

Although composed of feathers and tips, this product is not handled.

The 25 work spindles are very special and precise, guaranteeing extreme safety.

The small key takes up very little space and, thanks to its scratch-proof design, will not damage pockets, trouser pockets, etc.

]]> <![CDATA[Disec CLS5 Diamond Line: The only class 5 certified defender.]]> Sun, 07 Jul 2024 09:42:46 +0000 How is Disec CLS5 composed? Today we are talking about an open-slot protector for European cylinder locks rated CLASS 5. This defender has passed a thousand really brute burglary tests. Its body is studded with details that make this protector a truly impassable security device, and combined with a high-security cylinder will allow you to secure your security door without using multiple keys. The Body The Disec CLS5 is composed of the steel body with inserts inside it made of hard metals and details made of Diamond-based chips. This material has been researched and patented by Disec and does not allow any cutting technology such as: Flex, drills with special bits, etc… The key slot Unlike its competitors, this product has a deeper key slot precisely because to protect against the extraction of the European cylinder rotor (a technique widely used in isolated areas) it is studded with balls, plates and pins that do not allow milling, so removal of the washer on this protector is not allowed. This detail forced Disec to lengthen the key slot washer housing. His insignia The insignia of the Disec CLS5 is a really sturdy insignia, because made in a shelled shape it makes gripping impossible. In addition to this particularity Disec has well decided that the escutcheon has a millimeter and minute adjustment thanks to its threaded adjustment system. A system that will make perfect installation on your door so as not to create annoying play as they occur on traditional spring defenders. Obviously being the Diamond version inside the badge there are diamond-based plates to protect against drilling and removal of the badge. Factors to consider: Although perfectly designed, this product has some details to consider: It should always be combined with cylinders that have key necks at least 15 mm long. The hole on the door needs to be at least 56/57 mm, since it has an inner reveal of 54 mm. As an open-slot defender it should always be combined with a high-security anti-manipulation cylinder. Verify that you purchase the defender with the appropriate depth for your door. More product photos:

How is Disec CLS5 composed?

Today we are talking about an open-slot protector for European cylinder locks rated CLASS 5. This defender has passed a thousand really brute burglary tests. Its body is studded with details that make this protector a truly impassable security device, and combined with a high-security cylinder will allow you to secure your security door without using multiple keys.

The Body

The Disec CLS5 is composed of the steel body with inserts inside it made of hard metals and details made of Diamond-based chips. This material has been researched and patented by Disec and does not allow any cutting technology such as: Flex, drills with special bits, etc…

The key slot

Unlike its competitors, this product has a deeper key slot precisely because to protect against the extraction of the European cylinder rotor (a technique widely used in isolated areas) it is studded with balls, plates and pins that do not allow milling, so removal of the washer on this protector is not allowed. This detail forced Disec to lengthen the key slot washer housing.

His insignia

The insignia of the Disec CLS5 is a really sturdy insignia, because made in a shelled shape it makes gripping impossible. In addition to this particularity Disec has well decided that the escutcheon has a millimeter and minute adjustment thanks to its threaded adjustment system. A system that will make perfect installation on your door so as not to create annoying play as they occur on traditional spring defenders. Obviously being the Diamond version inside the badge there are diamond-based plates to protect against drilling and removal of the badge.

Factors to consider:

Although perfectly designed, this product has some details to consider:

It should always be combined with cylinders that have key necks at least 15 mm long.

The hole on the door needs to be at least 56/57 mm, since it has an inner reveal of 54 mm.

As an open-slot defender it should always be combined with a high-security anti-manipulation cylinder.

Verify that you purchase the defender with the appropriate depth for your door.

More product photos:

]]> <![CDATA[Tokoz PRO300 version 2024: stainless steel disc technology]]> Sun, 07 Jul 2024 09:30:17 +0000 What is the Tokoz PRO 300? Today we’re talking about a security cylinder with disc technology, more specifically the PRO 300, manufactured in the Czech Republic by a little-known company in the security sector, Tokoz. The PRO 300 is the Czech brand’s low-cost line, offering a good level of security at an affordable price. The body The Tokoz PRO 300 has a modular zinc alloy body, with a clamping protection riveted directly onto the key insert, and extension modules designed to fit together to ensure stability (even with very long sizes). Its internal mechanism is made entirely of STAINLESS STEEL, with discs that form a unique combination. Inside is a single active pin which acts as a step counter and prevents the key from being withdrawn during rotation. The encryption compartment is inserted into the key insert from the rear, offering the cylinder excellent protection against removal. The hole is protected by a hardened steel disk which acts as a shield for the internal encryption. When the key is inserted, the discs are aligned by a quarter turn. Only when the key is the right one does it lock onto the bar, allowing the cam to rotate. Another special feature of this product is that the discs and their washers make the figure a single body. The key The key for the PRO 300 is made of ALPACCA, a light, resistant material. This new key has replaced the old brass key, which was too flexible and caused breakage. The key is flat and symmetrical. This feature makes the key reversible; its shape is reminiscent of the old double-bitted key technology. Of course, its disk system is much more secure, as at the end of the rotation, the cylinder only allows the key to be removed after resetting the cipher by a quarter-turn before removing the key. The ASYMMETRIC head offers excellent grip when turning, and thanks to the reduced number of pins and springs inside the cylinder, key insertion is very easy. The length of the key neck is approximately 16 mm, making the cylinder compatible with 90% of magnetic or mechanical security devices. Factors to consider : Although this product is made of carbide and offers protection against punctures and splinters, it must always be combined with magnetic or mechanical protection. The mechanism with stainless steel discs ensures slight friction during rotation, which is created by the friction of the individual discs. If you had a pin-and-spring cylinder before this product, you may find it annoying to have to reset the coding, because as soon as you open/close the lock, you are obliged to reset the key. More product photos :

What is the Tokoz PRO 300?

Today we’re talking about a security cylinder with disc technology, more specifically the PRO 300, manufactured in the Czech Republic by a little-known company in the security sector, Tokoz. The PRO 300 is the Czech brand’s low-cost line, offering a good level of security at an affordable price.

The body

The Tokoz PRO 300 has a modular zinc alloy body, with a clamping protection riveted directly onto the key insert, and extension modules designed to fit together to ensure stability (even with very long sizes).

Its internal mechanism is made entirely of STAINLESS STEEL, with discs that form a unique combination. Inside is a single active pin which acts as a step counter and prevents the key from being withdrawn during rotation. The encryption compartment is inserted into the key insert from the rear, offering the cylinder excellent protection against removal. The hole is protected by a hardened steel disk which acts as a shield for the internal encryption. When the key is inserted, the discs are aligned by a quarter turn. Only when the key is the right one does it lock onto the bar, allowing the cam to rotate. Another special feature of this product is that the discs and their washers make the figure a single body.

The key

The key for the PRO 300 is made of ALPACCA, a light, resistant material. This new key has replaced the old brass key, which was too flexible and caused breakage.

The key is flat and symmetrical. This feature makes the key reversible; its shape is reminiscent of the old double-bitted key technology. Of course, its disk system is much more secure, as at the end of the rotation, the cylinder only allows the key to be removed after resetting the cipher by a quarter-turn before removing the key.

The ASYMMETRIC head offers excellent grip when turning, and thanks to the reduced number of pins and springs inside the cylinder, key insertion is very easy. The length of the key neck is approximately 16 mm, making the cylinder compatible with 90% of magnetic or mechanical security devices.

Factors to consider :

Although this product is made of carbide and offers protection against punctures and splinters, it must always be combined with magnetic or mechanical protection.

The mechanism with stainless steel discs ensures slight friction during rotation, which is created by the friction of the individual discs.

If you had a pin-and-spring cylinder before this product, you may find it annoying to have to reset the coding, because as soon as you open/close the lock, you are obliged to reset the key.

More product photos :

]]> <![CDATA[Disec 3G Diamond Line: The only magnetic defender with diamond details.]]> Sun, 07 Jul 2024 09:15:56 +0000 What does the Disec 3G Diamond line look like? Today we’re talking about a magnetic protector for European cylinder locks with a very high level of security. This protector has passed a thousand brutal break-in tests. Its body is packed with details that make it a truly impenetrable security device. In combination with a high-security cylinder, you can use it to protect your security door with unrivalled armor plating. The body The Disec 3G diamond line is similar to the MAG3G version, but differs in that the rotating front part is made of hardened stainless steel to protect against drilling, and is supported at the rear by a manganese plate. Inside, there are carbide anti-piercing inserts and diamond-based chip details. This material has been developed and patented by Disec and prevents the penetration of any cutting technology into the defender, e.g. flex, drills with special tips, etc: Flex, drills with special tips, etc…. The filling function Key filling is achieved by rotating the hardened steel plate, which is operated by its key with a combination of vectors and positions. These details give the defender an extreme level of security with an unrivalled functional system. And thanks to the protection and detail with which it has been manufactured, drilling is a distant memory. Your badge The Disec 3G Diamond escutcheon is a very sturdy escutcheon, because it’s made in the shape of a shell so it can’t seize. In addition to this special feature, Disec has ensured that the escutcheons can be adjusted to millimetre precision thanks to the threaded interlocking system. A system that guarantees a perfect fit to your door, with no annoying play, as is the case with conventional spring wings. Naturally, the Diamond version is fitted with diamond plates inside the hardware to avoid drilling and dismantling. Factors to consider : Although this product is perfectly designed, there are a few details to bear in mind: It should always be combined with cylinders with a key neck length of at least 15 mm. The hole in the door must be at least 56/57 mm, as the door has a 54 mm inner seal. Even if you opt for a gold or bronze finish, the central part of the defender will always be in steel-colored tempered stainless steel. For added safety, remember to always close the defender, because if we leave it open, we make the roller shutter key. Make sure you buy the right mudguard for the depth of your door. More product photos :

What does the Disec 3G Diamond line look like?

Today we’re talking about a magnetic protector for European cylinder locks with a very high level of security. This protector has passed a thousand brutal break-in tests. Its body is packed with details that make it a truly impenetrable security device. In combination with a high-security cylinder, you can use it to protect your security door with unrivalled armor plating.

The body

The Disec 3G diamond line is similar to the MAG3G version, but differs in that the rotating front part is made of hardened stainless steel to protect against drilling, and is supported at the rear by a manganese plate. Inside, there are carbide anti-piercing inserts and diamond-based chip details. This material has been developed and patented by Disec and prevents the penetration of any cutting technology into the defender, e.g. flex, drills with special tips, etc: Flex, drills with special tips, etc….

The filling function

Key filling is achieved by rotating the hardened steel plate, which is operated by its key with a combination of vectors and positions. These details give the defender an extreme level of security with an unrivalled functional system. And thanks to the protection and detail with which it has been manufactured, drilling is a distant memory.

Your badge

The Disec 3G Diamond escutcheon is a very sturdy escutcheon, because it’s made in the shape of a shell so it can’t seize. In addition to this special feature, Disec has ensured that the escutcheons can be adjusted to millimetre precision thanks to the threaded interlocking system. A system that guarantees a perfect fit to your door, with no annoying play, as is the case with conventional spring wings. Naturally, the Diamond version is fitted with diamond plates inside the hardware to avoid drilling and dismantling.

Factors to consider :

Although this product is perfectly designed, there are a few details to bear in mind:

It should always be combined with cylinders with a key neck length of at least 15 mm.

The hole in the door must be at least 56/57 mm, as the door has a 54 mm inner seal.

Even if you opt for a gold or bronze finish, the central part of the defender will always be in steel-colored tempered stainless steel.

For added safety, remember to always close the defender, because if we leave it open, we make the roller shutter key.

Make sure you buy the right mudguard for the depth of your door.

More product photos :

]]>
