copy of 3

Up to 5 meters high, modular, the Free can cover the width of 160 cm with a single module. New mechanics allow extraordinary lightness and quietness during opening and closing operations, possible from both sides. It can be developed as a kit already assembled and enclosed in a practical package containing profiles, net and pre-loaded spring.

Allowable construction sizes:

Maximum width 160 cm and maximum height 500 cm

-

Measurements survey:

THE FILOGRASSO SRL ASSUMES NO RESPONSIBILITY 'ON INCORRECT MEASUREMENTS BY THE CUSTOMER, THE RETURN IS NOT' POSSIBLE IF THE GOODS HAVE THE MEASURES CONFORM TO THOSE SPECIFIED BY THE CUSTOMER WHEN ORDERING. IN CASE OF ERROR ON OUR PART WE WILL SOLVE THE PROBLEM AS QUICKLY AS POSSIBLE (RETURN NOT ACCEPTED ON CUSTOM-MADE ITEMS)

For proper operation, measurements should be surveyed at three points and the smallest of the three measurements should be entered into the configurator.

Example survey:

Width: Top (cm) 100.3 - Middle (cm) 100.1 - Bottom (cm) 100.4

Width to be entered (cm): 100.1

Height: Left Side (cm) 100.3 - Middle (cm) 100.1 - Right Side (cm) 100.4

Height to insert (cm): 100.1

-

Light Measure and Finished Measure:

Light Measure(precise dimension of the compartment)= exact measurement of the compartment, to this measure we will deflate the millimeters required for proper installation.

Finished Measurement(exact size of the insect screen)= exact measurement of the insect screen, to this measurement you have deflated YOU the millimeters needed for proper installation.

Finished Measurement (exact size of the insect screen) = Light measurement (precise dimension of the compartment) subtracting 2 mm

Example: Light measurement 100 cm = Finished measurement 99.8 cm

-

Color:

Available color detail

-

Nets:

Detail nets available

-

SHIPPING AND TIMING:

Shipment will be within 6/7 working days (excluding Saturday, Sunday and holidays) from the date of receipt of payment, by courier 3 working days for shipments to Italy and 5/10 days for shipments to Europe.

-

WARRANTY

The shipment being insured needs acceptance subject to control at unloading by the customer.

In the absence of this observation the Filograsso srl does not assume responsibility for any damage.
